Vacuum Furnace Door Seal Grease

Reapply a thin coating of vacuum grease as necessary.

Vacuum furnace door seal grease.

Click here to access the step by step instructions for the o ring or lip seal installation on a rotating vacuum furnace door. Despite what one may think excess vacuum grease does not aid in sealing and should be removed as it is a getter for shop debris which will interfere with the o ring s ability to seal. A wet organic or silicone compound based oils and greases b dry lubricants including ptfe teflon and metal dichalcogenide compounds e g. Wipe the door o ring and flange with a clean lint free rag before closing the door.

Lubricants for vacuum service are a diverse family of highly formulated products. The first q a community for vacuum furnace end users and operators. Do not grease the lip seal. Check the o ring vacuum seal on the furnace door for grit and dirt that might cause vacuum leaks.

A damaged door seal vacuum furnace leaks and or hot zone contamination. The door seal on a vacuum furnace sees some of the highest wear and tear through normal operation. Vacuum grease which you should use on the face of the seal and why methods for keeping the seal off the ground and clean during the installation process. As such it tends to be the cause of pump down issues about 80 of the time.

The types of lubricants for vacuum service fall into three general categories. Figure 11 16 debris ladden door seal. On o ring seals look for cracks lack of elasticity flat spots dirt and metallic fines. Molybdenum disulfide tungsten diselenide and c metal on metal combinations.

Clean the chamber door or bottom head flange and lightly grease the o ring with a thin coating of high quality vacuum grease. Here the vapor pressure of the grease should be noted increases greatly with the temperature and should be well below the desired operating pressure. The vacuum grease smooth out small irregularities on the sealing surfaces and the surface of the o ring and thereby improves particularly at low degrees of deformation the sealing effect. How to seal a leaking o ring with grease.

Inspect and wipe clean this seal each time the door is opened after a furnace cycle. 1 if the door that houses the lip seal rotates the lip seal should be lubricated with dry graphite powder. If the pumping system is operating correctly then one of these failure modes is likely the cause.
